Hydrant and Hose Cabinet

The EMACO Hydrant and Hose Cabinet serves as a protective steel enclosure for fire hoses, valves, nozzles and related hardware, keeping emergency equipment visible, accessible and shielded from exposure.

Engineering overview

Used within a fire-protection system, the EMACO Hydrant and Hose Cabinet functions as a dedicated enclosure that protects hydrant and hose equipment while keeping it organized for emergency access. Select cabinet dimensions and sheet thickness from the equipment arrangement, hose size, mounting method and required environmental protection. The cabinet shields hoses, valves and nozzles from dust, moisture, salt air, chemicals, sunlight and accidental damage. EMACO also lists hose pin racks, adapters and rack nipples for use inside compatible hydrant boxes. Mount the cabinet where the door opens fully and equipment can be withdrawn without obstruction. Coordinate pipe penetrations, glazing, signage and locking method. Before purchase, lock down the model, approval status, material, rating, connection details and supplied accessories. The installed assembly must follow the approved drawings, product data and governing fire-protection standard.

Technical Q&A

What should the design team review before selecting the EMACO Hydrant and Hose Cabinet?

Use the approved design criteria as the starting point. Select cabinet dimensions and sheet thickness from the equipment arrangement, hose size, mounting method and required environmental protection.

How does the EMACO Hydrant and Hose Cabinet fit into the approved system layout?

The component must match the design route and operating arrangement. Mount the cabinet where the door opens fully and equipment can be withdrawn without obstruction. Coordinate pipe penetrations, glazing, signage and locking method.

What belongs on the approved submittal for the EMACO Hydrant and Hose Cabinet?

The submittal must match the final offer. Confirm cabinet dimensions, material, sheet thickness, IP or weatherproof requirement, finish, internal equipment and mounting details.

Technical specifications

Specification	Product information
Models	Cabinet dimensions and configuration to suit the selected assembly
Size / capacity	Multiple cabinet dimensions; confirm the offered enclosure
Working pressure	Confirm against the selected model documentation.
Connections	Confirm connection type and size against the approved design.
Materials / finish	Steel cabinet; red finish
Documented standards	Confirm applicable listing for the exact offered model.

Resources & documents

Access available datasheets and certificates through the protected resources portal. For model-specific submittals, send your project requirements to our technical team.

Model details

HOSE PIN RACK ADAPTER RACK NIPPLE Model EN0155-R (Standard) Model EN0156 (Standard) Model EN0155-N (Standard) Fire Hose Rack is a semi-automatic pin rack. Pre-loaded with movable pins and an automatic release mechanism that keeps water out of the hose until the last fold is removed. Body Material: Red enameled steel Fire Hydrant Adapter is a connector accessory. It has female NST threads on one side and BS 336 female instantaneous on the other. It is used to connect fire hose to pipe threads in conjunction with the swinging hose rack or with a hose valve for hydrant box. Rack Nipple is a cast brass hex nipple connector accessory. It has male NST threads on one side and male hose thread on the other. It is used to connect fire hose to pipe threads in conjunction with the swinging hose rack.
