Y Strainer
The EMACO Y Strainer is a pipeline strainer that captures debris before it reaches valves, pumps, meters and discharge devices in fire-water and industrial systems.
- Model options: UL
- 50 mm to 300 mm sizes
- Up to 21 bar pressure ratings
- Flanged and grooved configurations
- Fusion-bonded epoxy coating
Engineering overview
EMACO identifies the Y Strainer as a protective piping component used to remove solid particles from flowing water before sensitive downstream equipment for fire-protection installations. Select size, screen perforation, pressure rating and connection from the downstream equipment requirement and expected debris loading. Install in the approved orientation with room to remove the screen and route the blow-off or drain safely where provided. The Y-shaped body holds a removable screen in the flow path, allowing collected debris to be cleaned through the branch. EMACO lists flanged and grooved models with graphite or rubber gasket temperature ranges. Procurement needs more than a catalogue title: record the exact model, approval, materials, rating, connection and supplied accessories. Site work, commissioning and periodic maintenance must follow the approved system design and data sheet.
Technical Q&A
Which EMACO Y Strainer configuration suits the design duty?
Start with the hydraulic duty and site constraints. Select size, screen perforation, pressure rating and connection from the downstream equipment requirement and expected debris loading.
Where does the EMACO Y Strainer connect in the fire-protection system?
Follow the approved layout. Install in the approved orientation with room to remove the screen and route the blow-off or drain safely where provided.
What must be checked before the EMACO Y Strainer is ordered?
Compare the offer with the approved submittal before release. Confirm model, size, pressure, connection, screen material and opening, gasket, coating, drain provision, pressure drop and listing.
Technical specifications
|
Specification
|
Product information
|
|---|---|
|
Models
|
UL; E0230 (BS EN 1092-2 flange); E0230 (ASME/ANSI B 16.1 flange); E0231-300 E0231-250 E0231-200 E0231-PN16 E0231-PN10; STANDARD; EN0230 (EN standard); EN0231-300 EN0231-250 EN0231-200 EN0231-PN16 EN0231-PN10
|
|
Size / capacity
|
SIZE, Nominal Pipe Size: 2’’ – 12’’ (50 – 300mm )
|
|
Working pressure
|
RATED WORKING PRESSURE: 233psi (16.1bar); 300psi (21bar); 300psi (21bar) 250psi (17bar) 200psi (14bar) 233psi (16.1bar) 175psi (12bar)
|
|
Connections
|
END CONNECTION: Flange; Groove end configuration
|
|
Materials / finish
|
Refer to model documentation.
|
|
Documented standards
|
Request model-specific documentation.
|
Resources & documents
Access available datasheets and certificates through the protected resources portal. For model-specific submittals, send your project requirements to our technical team.
Model details
MODEL: UL | MODEL: STANDARD | END CONNECTION: | SIZE, Nominal Pipe Size: | RATED WORKING PRESSURE:
MODEL: E0230 (BS EN 1092-2 flange) | MODEL: EN0230 (EN standard) | END CONNECTION: Flange | SIZE, Nominal Pipe Size: 2’’ – 12’’ (50 – 300mm ) | RATED WORKING PRESSURE: 233psi (16.1bar)
MODEL: E0230 (ASME/ANSI B 16.1 flange) | MODEL: EN0230 (EN standard) | END CONNECTION: Flange | SIZE, Nominal Pipe Size: 2’’ – 12’’ (50 – 300mm ) | RATED WORKING PRESSURE: 300psi (21bar)
MODEL: E0231-300 E0231-250 E0231-200 E0231-PN16 E0231-PN10 | MODEL: EN0231-300 EN0231-250 EN0231-200 EN0231-PN16 EN0231-PN10 | END CONNECTION: Groove end configuration | SIZE, Nominal Pipe Size: 2’’ – 12’’ (50 – 300mm ) | RATED WORKING PRESSURE: 300psi (21bar) 250psi (17bar) 200psi (14bar) 233psi (16.1bar) 175psi (12bar)
