Pendent Sprinkler

For fire-protection work, the EMACO Pendent Sprinkler is an automatic pendent sprinkler installed below finished ceilings to discharge a designed water pattern after its thermal element reaches the rated temperature.

Engineering overview

The EMACO Pendent Sprinkler performs one defined job: it serves as a automatic ceiling sprinkler that directs water downward over the protected area when its heat-responsive element operates. EMACO lists standard-response and quick-response pendent models with multiple temperature ratings. The sprinkler is intended for installation below finished ceilings and may be coordinated with adjustable or fixed escutcheon plates. Install at the listed distance below the ceiling, maintain required spacing and clearance, and keep paint or ceiling material away from the operating parts. Choose response type, temperature, K-factor and finish from the hazard, occupancy, hydraulic calculation and ceiling design. The order should identify the offered model, applicable approval, materials, rated pressure or capacity, connection arrangement and accessories. Field installation and acceptance testing follow the design documents and selected product data.

Technical Q&A

How should the EMACO Pendent Sprinkler be sized or selected?

Begin with the required flow, pressure, connection and service conditions. Choose response type, temperature, K-factor and finish from the hazard, occupancy, hydraulic calculation and ceiling design.

How should the EMACO Pendent Sprinkler be arranged in the system?

The system arrangement controls this. Install at the listed distance below the ceiling, maintain required spacing and clearance, and keep paint or ceiling material away from the operating parts.

What should procurement verify for the EMACO Pendent Sprinkler?

Confirm the technical schedule before placing the order. Confirm model or SIN, response type, 5.6 K-factor, 12 bar rating, temperature, thread, escutcheon and approval.

Technical specifications

Specification	Product information
Models	EM005; EM006
Size / capacity	Refer to model documentation.
Working pressure	WORKING PRESSURE: 175psi (12bar)
Connections	Confirm for the selected model.
Materials / finish	DEFLECTOR MATERIAL: Brass
Documented standards	Request model-specific documentation.

Resources & documents

Access available datasheets and certificates through the protected resources portal. For model-specific submittals, send your project requirements to our technical team.
